MVK I/O COMPACT MODULE, METAL
Product may differ from image

MVK I/O COMPACT MODULE, METAL

CANopen, 16 multifunctionale channels
Art.No.: 55306
Weight: 0.822 kg
 製品比較

You might also like

デジタル入力/出力
DIO8 DIO8
CAN 1 Mbit/s; M12, Aコード
7/8", 5極, 2× 最大9 A
M12, 5極, Aコード
FSU (Fast-Start-Up)
接続ケーブルは、オンラインショップの「接続技術」の項目にあります。
ハウジングは樹脂ポッティング加工済み
Module supply
Operating voltage 24 V DC (EN 61131-2)
General data
Mounting method 2-hole screw mounting
Temperature range 0...+55 °C (storage temperature -20...+70 °C)
Protection IP67
Dimensions H×W×D 42×63×225 mm
Output
Lamp load 10 W
Actuator supply UA 24 V DC (EN 61131-2), max. 9 A
Switching current per output max. 1.6 A (short-circuit and overload protected)
Input
Sensor supply US 24 V DC (EN 61131-2), max. 200 mA (M12 female), short-circuit and overload protected
Type for 3-wire sensors or mechanical switches, PNP
Parameterization
PIN 4 Input/Output
PIN 2 Input/Output/Diagnostic
Connections
Fieldbus CAN 1 Mbit/s; M12, A-coded
Sensor-system/actuator supply 7/8", 5-pole, 2× max. 9 A
I/O ports M12, 5-pole, A-coded
CANopen
Addressing Rotary switch 1...99
Diagnostic
Communication status via LED
Diagnostic via LED per module and channel
Diagnostic via BUS per module and channel
Actuator warning per channel via LED and BUS
Monitoring - under voltage yes
Monitoring - no voltage yes
Short-circuit and overload yes
Cable break per port
取引条件
EAN 4048879051491
eClass 27242604
HSコード 85176200
Packaging unit 1.000
生産現国 DE
Data cableShow all
Power cableShow all
Sensor-actuator cableShow all

Data Regarding Article:
  • Download Data Sheet
  • Download Approvals and certificates 55306_918-04.16_ce_z_c.pdf
  • Download Approvals and certificates 55306_0000004f-cia200401-301v402-20-0027-Feb04_can_z_b.pdf
  • Download Approvals and certificates 55306_E201820_NRAQ7_ulc_z_a.pdf
  • Download Approvals and certificates 55306_E201820-NRAQ_ul_z_b.pdf
  • Download China RoHS information EPUP-25_CHR_x_1.pdf
  • Download Configuration Files MVK-MC_55306.zip
  • Download Drawing Files 55304_p8_2_50.zip
  • Download Drawing Files 55294_stp_x_a.zip
  • Download Drawing Files 55306_p8_2_50.zip
  • Download Drawing Files 55294_dxf_x_a.zip
  • Download Installation Instructions 55304_ina_6_22.pdf
  • Download Manuals 55388_hdb_x_12.zip
