MVK I/O COMPACT MODULE, METAL
Product may differ from image

MVK I/O COMPACT MODULE, METAL

CANopen, 16 multifunctionale channels
Art.No.: 55306
Weight: 0.822 kg
 Product Comparison

You might also like

Digital inputs/outputs
DIO8 DIO8
CAN 1 Mbit/s; M12, A-coded
7/8", 5-pole, 2× max. 9 A
M12, 5-pole, A-coded
FSU (Fast-Start-Up)
Connection cables are in the online shop under "Connection Technology". Housing fully potted.
Input
Sensor supply US 24 V DC (EN 61131-2), max. 200 mA (M12 female), short-circuit and overload protected
Type for 3-wire sensors or mechanical switches, PNP
Connections
Fieldbus CAN 1 Mbit/s; M12, A-coded
Sensor-system/actuator supply 7/8", 5-pole, 2× max. 9 A
I/O ports M12, 5-pole, A-coded
Module supply
Operating voltage 24 V DC (EN 61131-2)
CANopen
Addressing Rotary switch 1...99
General data
Protection IP67
Mounting method 2-hole screw mounting
Dimensions H×W×D 42×63×225 mm
Temperature range 0...+55 °C (storage temperature -20...+70 °C)
Output
Actuator supply UA 24 V DC (EN 61131-2), max. 9 A
Switching current per output max. 1.6 A (short-circuit and overload protected)
Lamp load 10 W
Parameterization
PIN 4 Input/Output
PIN 2 Input/Output/Diagnostic
Diagnostic
Communication status via LED
Diagnostic via LED per module and channel
Diagnostic via BUS per module and channel
Monitoring - under voltage yes
Monitoring - no voltage yes
Short-circuit and overload yes
Actuator warning per channel via LED and BUS
Cable break per port
Commercial data
country of origin DE
customs tariff number 85176200
EAN 4048879051491
eClass 27242604
Packaging unit 1

Data Regarding Article:
  • Download Data Sheet
  • Download Approvals and certificates 55306_0000004f-cia200401-301v402-20-0027-Feb04_can_z_b.pdf
  • Download Approvals and certificates 55306_E201820_NRAQ_ul_z_a.pdf
  • Download Approvals and certificates 55306_918-04.16_ce_z_c.pdf
  • Download Approvals and certificates 55306_E201820_NRAQ7_ulc_z_a.pdf
  • Download China RoHS information EPUP-25_CHR_x_1.pdf
  • Download Configuration Files MVK-MC_55306.zip
  • Download Drawing Files 55294_stp_x_a.zip
  • Download Drawing Files 55304_p8_2_50.zip
  • Download Drawing Files 55306_p8_2_50.zip
  • Download Drawing Files 55294_dxf_x_a.zip
  • Download Installation Instructions 55304_ina_6_22.pdf
  • Download Manuals 55388_hdb_x_12.zip
cULus
CANopen
