MVP12, 6XM12, 5POLE, PLUG. TERM.
Product may differ from image

MVP12, 6XM12, 5POLE, PLUG. TERM.

W/o cap, with pot. separation, w/o LED's
Art.No.: 276577
Weight: 0.077 kg
 Product Comparison

You might also like

6-way, 5-pole
Basic module without LED
Potential separation as option
Plastic housings with good resistance against chemicals and oils.
The resistance to aggressive media should be individually tested for your application. Further details on request.
Further cable lengths on request.
Technical Data
Operating voltage 24 V DC
Operating current per contact max. 4 A
Locking of ports Screw thread (M12×1 mm)
Protection IP67 inserted and tightened (EN 60529)
Housing Plastic, flame retardant
Signal per port 2
Total current max. 2× 8 A
General data
Temperature range -20...+80 °C
Dimensions H×W×D 124.2×50.2×16.5 mm
Contact Layout
PIN 1 (+)
PIN 2 (NC)/(S2)
PIN 3 (-)
PIN 4 (NO)/(S1)
PIN 5 (Earth)
Commercial data
country of origin DE
customs tariff number 85369010
EAN 4048879061742
eClass 27279219
Packaging unit 1.000

Data Regarding Article:
  • Download Data Sheet
  • Download Approvals and certificates 276577_E201820-NRAQ_ul_z_a.pdf
  • Download Approvals and certificates 276577_11-06.17_ce_z_a.pdf
  • Download Approvals and certificates 276577_E201820-NRAQ7_ulc_z_a.pdf
  • Download China RoHS information EPUP-E_CHR_x_1.pdf
Approvals
