Expansion module
DIO12 IOL4 (E) - 8× M12
IO-Link Master V1.0
Digital inputs/outputs (multifunctional)
Connection cables are in the online shop under "Connection Technology".
Housing fully potted.
Cube67+ modules can only be operated on Cube67+, EtherNet/IP, PROFIBUS + PROFINET bus nodes.
DIO12 IOL4 (E) - 8× M12
IO-Link Master V1.0
Digital inputs/outputs (multifunctional)
Connection cables are in the online shop under "Connection Technology".
Housing fully potted.
Cube67+ modules can only be operated on Cube67+, EtherNet/IP, PROFIBUS + PROFINET bus nodes.
General data
| Mounting method | 2-hole screw mounting |
|---|---|
| Temperature range | 0...+55 °C (storage temperature -20...+75 °C) |
| Compatible with: | 56521; 56526 |
| Protection | IP67 |
| Dimensions H×W×D | 126×30×34.5 mm |
Output
| Lamp load | 30 W |
|---|---|
| Actuator supply UA | 24 V DC (EN 61131-2), via system connection (max. 4 A) |
| Switching current per output | max. 1.6 A (short-circuit and overload protected) |
Input
| Sensor supply US | 24 V DC (EN 61131-2), max. 200 mA (port 0...3); max. 700 mA (port 4...7) |
|---|---|
| Type | for 3-wire sensors or mechanical switches, PNP |
| Input filter | 1 ms |
IO-Link
| Specification | IO-Link Master V1.0 |
|---|---|
| Port Class | Class A + B (not galvanically separated) |
| IO-Link | 4× Master |
| Transfer parameters | 32 Byte (per IO-Link port) |
| Operating modes | COM1; COM2; COM3 (automatic) |
Internal communication
| LED display | US: sensor supply and internal supply voltage (green: OK); UA: actuator supply (green: OK) |
|---|---|
| Current consumption | max. 100 mA |
Parameterization
| PIN 4 | Input/Output (port 0...3); IO-Link Master (port 4...7) |
|---|---|
| PIN 2 | Input/Output/Diagnostic |
Connections
| Fieldbus | via internal system connection |
|---|---|
| Sensor-system/actuator supply | via internal system connection (max. 2× 4 A) |
| I/O ports | M12 (female) 5-pole, A-coded |
Diagnostic
| Communication status | via LED |
|---|---|
| Diagnostic via LED | per module and channel |
| Diagnostic via BUS | per module and channel |
| Actuator warning | per channel via LED and BUS |
| Monitoring - under voltage | yes |
| Monitoring - no voltage | yes |
| Short-circuit and overload | yes |
Commercial data
| country of origin | DE |
|---|---|
| customs tariff number | 85389099 |
| EAN | 4048879326766 |
| eClass | 27242604 |
| Packaging unit | 1.000 |
