EMPARRO CAP BUFFER MODULE

IN: 24VDC OUT: 24VDC/20A for max. 1A/40s
Art.No.: 85458
Alternative product:    85414
Weight: 0.781 kg
Country of origin:  DE
 Product Comparison

Description

INPUT: 24 V DC (SELV/PELV)
OUTPUT: max. 20 A
1.0 s (20 A); 40 s (1 A)
Approvals

General data
Standards EN 61000-6-2, EN 61000-6-4
Mounting method DIN-rail mountable TH35-7.5/TH35-15 (EN 60715)
Temperature range -40...+60 °C (storage temperature -40...+60 °C)
Efficiency min. 90%
Dimensions H×W×D 123×65×138 mm
Output
Output voltage 25.5...19 V DC ±2%
Parallel circuit possible
Current limit 65 A
Buffer time 1.0 s (20 A); 40 s (1 A)
Output current max. 20 A
Input
Input voltage 21.6...26.4 V DC
Inrush current max. 25 A
Loading current max. 3 A
Loading time max. 75 s

customs tariff number 85322900
EAN 4048879436700
eClass 27049190
Packaging unit 1.000
