EVOLUTION POWER SUPPLY 3-PHASE,
Product may differ from image

EVOLUTION POWER SUPPLY 3-PHASE,

IN: 360-520VAC OUT: 22-28V/20ADC
Art.No.: 85002
Alternative product:    85692
Weight: 2.157 kg
 Product Comparison

You might also like

INPUT: 3× 360...520 V AC / 480...745 V DC
OUTPUT: 22...28 V DC
Current: 20 A
General data
Standards IEC 61010-2-201, EN 61204-3, EN 55011 A, EN 61000-3-2, SEMI F47
Mounting method DIN-rail mountable TH35 (EN 60715)
Temperature range -25...+70 °C (storage temperature -40...+85 °C)
Relative humidity 5...95%, no condensation
Protection IP20
Efficiency 90% (3× 400 V AC); 89% (3× 520 V AC)
Connection Screw terminals
Dimensions H×W×D 132×113×136 mm
Output
Output voltage 24 V DC (SELV), ±1%; 22...28 V adjustable
Power Boost Iout N × 150% (min. 4 s)
LED display LED (green): OK; LED (red): overload
Output current 20 A (+55 °C); 15.8 A (+70 °C)
Mains failure bridging time min. 19 ms (400 V AC)
Ripple max. 50 mV eff/rms
Spikes max. 100 mV ss/pp
Unit protection short-circuit and overload protected
Parallel usage/serial usage max. 5 units/max. 2 units
Input
Input voltage 3× 324...572 V AC/480...745 V DC
Primary fusing external max. 3× 20 A
Input current 3× 1.3 A
Inrush current after 1 ms max. 19 A
Frequency 50...60 Hz
Commercial data
country of origin CZ
customs tariff number 85044090
EAN 4048879000093
eClass 27049002
Packaging unit 1.000

Data Regarding Article:
  • Download Data Sheet
  • Download Approvals and certificates 85002_E222272-NMTR7_ulc_z_a.pdf
  • Download Approvals and certificates 85002_TAA00000YF- DNVGL-2021.01.27_gl_z_b.pdf
  • Download Approvals and certificates 85002_42-10.20_ce_z_c.pdf
  • Download Approvals and certificates 85002_E222272-NMTR_ul_z_b.pdf
  • Download China RoHS information EPUP-50_CHR_x_1.pdf
  • Download Drawing Files 85002_dxf_x_a.zip
  • Download Drawing Files NETZGERAETE.zw1
  • Download Drawing Files 85002_stp_x_a.zip
  • Download Installation Instructions 85002_ina_4_16.pdf
Approvals
Approvals
